InduSmart® Panel-PC RedLine 15.6"

InduSmart® RedLine Panel PC for High Performance HMI Applications

The InduSmart® RedLine Panel PC is a high performance industrial panel PC built for demanding HMI applications and complex system environments.

It is designed for projects where processing power, system integration, and flexibility are critical. This panel PC combines strong computing performance with an open system architecture and broad connectivity.

advantages

  • Industrial panel PC with Intel Core platform
  • High performance for data intensive applications
  • Open system architecture
  • Fanless design for reliable continuous operation; industrial design with IP65 protected front
  • Windows preinstalled with support for additional operating systems
  • Long term availability
  • Multiple interfaces including LAN, USB, and HDMI
Do you have any questions about the product or do you need further information? Just give us a call! You can reach our sales team at:

Your Product request

You may unsubscribe from these communications at any time. For more information on how to unsubscribe, our privacy practices, and how we are committed to protecting and respecting your privacy, please review our Privacy Policy.

GETT Asia Ltd. is committed to protecting and respecting your privacy. We use your personal data solely for managing your account and providing the products and services you have requested. From time to time, we would like to inform you about our products and services, as well as other content that may be of interest to you.

For information on how to unsubscribe, as well as our privacy practices and commitment to protecting your privacy, check out our Privacy Policy.

Please observe the Terms & Conditions of GETT Asia Ltd.

In order to provide you the content requested, we need to store and process your personal data. If you consent to us storing your personal data for this purpose, please tick the checkbox below.

Order data*

KURZBEZEICHNUNGARTIKELNUMMERFarbe
InduSmart Panel-PC RedLine 15,6"
IPRD004.
schwarz

*Further layouts and individual customisation available on request. MOQ´s apply.

Technical data

  • Area of application:
    industrial
    Guarantee / Warranty:
    2 Jahre Garantie

    Material:

    Front material:
    Glas
    Housing colour:
    schwarz
    Housing material:
    Stahlblech verzinkt
  • Temperature ranges:

    min. storage temperature:
    -20°C
    max. storage temperature:
    75°C
    min. operating temperature:
    0°C
    max. operating temperature:
    50°C
    max. humidity:
    95%

    Fastening:

    Number of fixing points:
    4
    Fastening type:
    VESA
    Thread:
    M4
    Distance X:
    75.00 mm
    Distance Y:
    75.00 mm

    Product dimensions:

    Length (width):
    396.80 mm
    Width (depth):
    253 mm
    Height:
    81.70 mm
    Weight:
    4kg
  • Single Board Computer (SBC):


    card slots:

    Working memory:


    HDD / SSD:


  • USB interfaces:

    Display & Audio:

    LAN / WLAN:

  • Display

  • Electrical data:

    Operating voltage:
    24 V
  • Declarations & Certifications:

    • CE

    • EMV*

    • REACH*

    * Explanations available on request

Downloads
